The Box Opening Pressure Tester measures opening force of flat stacked carton boxes. The instruments is uesful in the process of research and development. As well as the quality control during the production of cartons. Thereby, reducing risks and speeding up production set-up time.
Test Stand Features
The Box Opening Pressure Tester has a motorized test stand. This is a highly configurable single column force tester for tension and compression measurement applications. That is up to 300 lbF (1.5kN). It has a rugged design Thus, is suitable for laboratory and production environments. It also comes with a generous travel, clearance and depth dimensions. Therefore, a wide range of tests can be performed, including break testing, cycling, limit testing to a load or distance. As well as load holding, elongation testing, tensile testing, compression testing and more.
With generous travel, clearance, and depth dimensions, a wide range of tests can be performed, including break testing, cycling, limit testing to a load or distance, loadholding, elongation testing, tensile testing, compression testing, and more. Satisfy various test methods through an easy-to-use menu, allowing the configuration of test speed, force and distance limits, cycling, preload, and many other functions, all protected by a password. Save up to 50 profiles to accommodate a range of test methods.
Special features of Box Opening Pressure Tester
|
Simple controller interface
Rugged aluminium up/down/stop keys are designed for industrial environments. Zero travel and FollowMe™ keys add convenience. It can also be removed for remote use.
|
 |
|
Limit switches
Adjustable upper and lower solid state limit switches stop test stand travel with 0.001 in. repeatability.
|
 |
|
Travel Indication (optional)
Travel is indicated on the control unit display, with output via USB. The most recent position is displayed upon powering on. An internal scale utilizing Renishaw technology produces significantly higher accuracy than with conventional rotary encoder-based designs. Backlash and nonlinearity are virtually eliminated.
|
|
Programmable travel limits (optional)
The stand stops at or cycles between programmable upper and lower travel distances.
|
